Brand | Woodford Pankhurst 4, 5 or 8 |
---|---|
Fuel | Wood Burning |
Output | 4, 5 or 8kW |
Width | 358mm | 410mm | 478mm (4, 5, 8kW) |
Depth | 271mm | 330mm | 330mm (4, 5, 8kW) |
Height | 431mm | 522mm | 553mm (4, 5, 8kW) |
Flue Diameter | 125mm (5") |
Efficiency (%) | 75.6% to 79% |
Energy Rating | A+ |
Flue Placement | Top or Rear (Interchangable) |
Made Of | Steel Body, Cast Iron Door |
Colour | Black |
Depth From Back to Centre of Top Flue | |
Height to Centre of Rear Flue | |
Log length | 238mm | 290mm | 358mm (4, 5, 8kW) |
Distance To Combustibles - Sides | 500mm | 400mm | 450mm (4, 5, 8kW) |
Distance To Combustibles - Rear | 550mm | 400mm | 550mm (4, 5, 8kW) |
Can Go On 12mm Hearth | No |
External Air | Yes |
Parts Warranty | 1 Year |
Warranty | Lifetime |
Brand | Woodford Turing 5, 5X or 5XL (same as The Lowry with a different door styling) |
---|---|
Fuel | Wood Burning & Multifuel |
Output | 5kW |
Width | 350mm | 495mm | 522mm (5, 5X, 5XL) |
Depth | 280mm | 320mm | 290mm (5, 5X, 5XL) |
Height | 487mm | 585mm | 600mm (5, 5X, 5XL) |
Flue Diameter | 125mm (5") |
Efficiency (%) | 75.6% to 86% |
Energy Rating | A+ |
Flue Placement | Top or Rear (Interchangable) |
Made Of | Steel Body, Cast Iron Door |
Colour | Black |
Depth From Back to Centre of Top Flue | |
Height to Centre of Rear Flue | |
Log length | 280mm | 375mm | 400mm (5, 5X, 5XL) |
Distance To Combustibles - Sides | 600mm |
Distance To Combustibles - Rear | 800mm |
Can Go On 12mm Hearth | Yes |
External Air | Yes |
Parts Warranty | 1 Year |
Warranty | Lifetime |
Brand | Woodford Lowry |
---|---|
Fuel | Wood Burning |
Output | 5kW |
Width | 350mm |
Depth | 280mm |
Height | 487mm |
Flue Diameter | 125mm (5") |
Efficiency (%) | 75.6% |
Energy Rating | A+ |
Flue Placement | Top or Rear (Interchangable) |
Made Of | Steel Body, Cast Iron Door |
Colour | Black |
Depth From Back to Centre of Top Flue | |
Height to Centre of Rear Flue | |
Log length | 300mm |
Distance To Combustibles - Sides | 500mm |
Distance To Combustibles - Rear | 600mm |
Can Go On 12mm Hearth | No |
External Air | Yes |
Parts Warranty | 1 Year |
Warranty | Lifetime |
Brand | Woodford Chadwick 5, 8 or 12kW |
---|---|
Fuel | Wood Burning & Multifuel |
Output | 5, 8, 12kW |
Width | 475mm | 582mm | 582mm (5, 8, 12kW) |
Depth | 260mm | 260mm | 300mm (5, 8, 12kW) |
Height | 530mm | 575mm | 575mm (5, 8, 12kW) |
Flue Diameter | 125mm (5") |
Efficiency (%) | 75.6% to 81% |
Energy Rating | A |
Flue Placement | Top or Rear (Interchangable) |
Made Of | Steel Body, Cast Iron Door |
Colour | Black |
Depth From Back to Centre of Top Flue | |
Height to Centre of Rear Flue | |
Log length | 360mm | 460mm | 460mm (5, 8, 12kW) |
Distance To Combustibles - Sides | 400mm 400mm 400mm (5, 8, 12kW) |
Distance To Combustibles - Rear | 700mm 700mm 700mm (5, 8, 12kW) |
Can Go On 12mm Hearth | Yes |
External Air | Yes |
Parts Warranty | 1 Year |
Warranty | Lifetime |
